CF120 WH
COLOR
white
MODEL
CF120 WH
MB Controlled 120mm A-RGB LED Case Fan
CUSTOMIZABLE ADDRESSABLE RGB LED LIGHTING
Utilize 12pcs of independently programmable RGB LED lights, CF120 WH provides full lighting for your build, achieving magical lighting effects with MB controls include 3 dynamic modes(waves, cycles and breathing) and 3 monochrome modes (constant light, breathing and meteor), up to 6 different colors to choose from
Synchronized Control via 5V A-RGB Header on MB
Can be easily controlled by MB through 5V A-RGB Header, no additional controller needed, and can synchronize with other A-RGB devices
Better Balance on Performance & Low Noise
Better balance on air volume & air pressure, low noise, can be used as a case fan or CPU cooling fan
Super Silent
ADD-RGB LED
PWM Intelligent Control
Fan speed can be intelligently controlled by MB in accordance with temperature
PWM Control
Technical Spec
Fan Dimensions120×120×25 mm(L×W×H)
Net Weight148 g
Fan Speed500~1500 RPM±10%
Fan Airflow57.28 CFM
Fan Air Pressure1.61 mmAq
Fan Noise28.5 dB(A)
Fan Connector4-pin PWM
Bearing TypeHydro Bearing
Fan Rated Voltage12VDC
Fan Rated Current0.11A
Fan Power Consumption1.32W
LED TypeAddressable RGB LED
LED Connector3-pin(+5V-D-G)
LED Rated Voltage5VDC
LED Power Consumption2.2 W
EAN6933412710639
P/NDP-FA-RGB-CF120WH-1
Product Dimension
