MATREXX 70

Novel Adaptibility

A new-concept chassis specially designed for the enjoyment of DIY. By adopting numerous novel structural designs, its architecture yields convenience and flexibility in PC building. As a mid-tower case, It′s also endowed with abundant space that supports up to E-ATX motherboard.

One-touch-release Front Panel

With the bottom hooked to case structure, and the top locked by a spring buckle, the front panel of MATREXX 70 can be released to “dismounting ready”state with just one touch.

Once the “OPEN” button is pressed, the front panel will be released and held at a 5°angel, and is ready to be pulled out.
Easy-to-install Side Panel

The side panel is fixed with 1 groove + 2 screws design, which makes installation much easier.

Plus, this unique fixation method will grant the glass panel even stress distribution, hence reduces the risk of cracking.

Removable Radiator Holder

The radiator holder simplifies the installation of liquid coolers and replacement of the radiators.It′s especially effort-saving when you need to install radiators or fans on different sides of the holder.

The holder supports up to 360mm radiator or 3*140mm fans.

Removable tinted tempered Glass PSU Shroud

In MATREXX 70, DeepCool creatively used tinted tempered glass as the top cover of PSU shroud, which is pioneering in the industry.

Lighting Effects of LED Strip on the Power Shield (LED Strips are not included in the case）

Flexible Ventilation Solutions with Excellent Performance

With air intake options at front and bottom, exhaust options at the top and rear, MATREXX 70 provides highly flexible ventilation solutions. Meanwhile the 15mm-wide front intake hole guarantees sufficient air supply, together with the low friction material applied on all meshes, the cooling efficiency is maximized.

Radiator Support

Motherboard support

E-ATX( Up to 330mm )
ATX
Micro-ATX
Mini-ITX
Abundant Storage Support

A total of 6* 2.5’’ drives or 4*2.5’’ + 2* 3.5’’ drives can be mounted in MATREXX 70. 2 SSD bays are fixed at the back of motherboard tray for quick installation. 2* 3.5/2.5’’ hard drive bays are mounted at the bottom of the case which are relocatable and removable.After removal, 2*120mm fans can be installed at the location.
Spacious Interior

The case's dimensions are 483×228×492mm, offering gigantic room to manage cables (170mm motherboard tray-to-glass clearance, 30mm motherboard tray-to-back plate clearance).

Graphic cards support up to 380mm

Equipped with large spacing - 170mm( Tower Room ) and 30mm ( cable sorting at the rear )

Four 2.5inch independent hard disk lots and two 3.5/2.5inch hard disk spaces.

As the dust screens are installed at the top, bottom and front, it provides remarkable anti-dust capabilities while being easy to clean.

Technical Spec

Motherboards	E-ATX/ATX/Micro ATX/Mini-ITX
Case Type	Middle Tower
Materials	ABS+SPCC+Tempered Glass
Product Dimensions (L×W×H)	483×228×492(L×W×H)
Net Weight	8.89 kg
Gross Weight	10.31 kg
5.25' Drive Bays	0
3.5' Drive Bays	2
2.5' Drive Bays	4
I/O Ports	2×USB3.0/1×USB2.0/1xAudio(HD)/1xMic
Expansion Slots	7 +2
Cooling Fans Support	Pre-installed: Rear: 1×120mm. Optional: Front: 3×120/140mm; Top: 3×120/140mm
Cable Management	30mm Clearance
Liquid Cooler Support	Front: 120/140/240/280/360mm radiator; Top: 120/140/240/280/360mm radiator; Rear: 120mm radiator
Power Supply Type	ATX PS2 (maximum length: 200mm)
CPU Cooler Height Limit	170mm
VGA Length Limit	380mm (horizontal)/360mm (vertical)
Carton Dimension (LxWxH)	537×285×539mm
EAN	6933412713753
P/N	DP-ATX-MATREXX70-BKG0P

Product Dimension

DeepCool Matrexx 70 Review - Is this E-ATX Case Worth $70...?!

Here is the DeepCool Matrexx 70, an E-ATX case. It offers the glass PSU shroud cover and quick detachable panels. Moreover, does it hold up good with the basics like temperatures and build quality? Let's check it out!

Download

MATREXX 70 Manual.pdf
